Low MOQ for China Olabo Manufacturer Bk-280 200 Tests Per Hour Auto Chemistry Analyzer
We emphasize advancement and introduce new products and solutions into the market each year for Low MOQ for China Olabo Manufacturer Bk-280 200 Tests Per Hour Auto Chemistry Analyzer, In buy to expand our international market, we mainly source our oversea customers Top top quality performance goods and services.
We emphasize advancement and introduce new products and solutions into the market each year for China Auto Chemistry Analyzer, Our factory insists on the principle of “Quality First, Sustainable Development”, and takes “Honest Business, Mutual Benefits” as our developable goal. All members sincerely thanks for all old and new customers’ support. We will keep working hard and offering you the highest-quality solutions and service.Thanks.
Parameter
Model | BK-200 | |
Overall Performance | Throughput | 200 Tests/hour |
Analysis Method | End-point, Fixed-time, Rate(Kinetic) | |
Certification | CE, ISO9001, ISO14001, ISO13485 | |
Sample & Reagent System | Sample Positions | 37 sample positions |
Reagent Positions | 28 reagent positions | |
Sample Volume | 2~70μl | |
Reagent Volume | 20~350μl | |
Probe | Teflon coating ,with anti-collision function, liquid leveldetection function | |
Probe Washing | Automatic washing interior and exterior | |
Reagent Cooling | Refrigerated tray with independent switch | |
Reaction System | Temperature Control | 37±0.1℃, real-time monitoring |
Cuvettes | 48 reusable cuvettes, optical length 6mm | |
Mixer Probe | Independent stirring | |
Washing | Automatic cuvettes washing | |
STAT function | YES | |
Optical System | Light Source | 6V/10W halogen lamp |
Spectrophotometry | Post-spectral spectrophotometry | |
Wavelength | 340,405,450,510,546,578,630,700nm | |
Absorbance | 0~3.0Abs | |
Calibration & QC | Calibration | Linear:K factor, 1-point, 2-point and multipoint linear Non-Linear:Spline,Polygon, Index, Ogarithm, Logit-4P, Logit-5P |
Quality Control | Real-time QC, Westgard multi rule, Cumulative Sum Check,Twin Plot(2D) | |
Data Management | Software | Windows 7/8/10 , 32or 64bit |
LIS System | Bi-direction,support HL7 protocol | |
Interface | LAN port access | |
Printer | External, multiple reporting mode available | |
Working Conditions | Power Supply | AC220V±10%,50/60Hz, 110V±10%,60Hz, 300W |
Temperature | 10~30℃ | |
Water Consumption | Deionized water:12L/H | |
Humidity | 30-80% | |
Size & Weight | External Size (W*D*H) | 625*425*460mm |
Net Weight | 36kg | |
Package Size (W*D*H) | 721*531*855mm | |
Gross Weight | 50kg |
Features
1. 37 Sample positions
2. 28 Reagent positions
3. 48 Reaction cuvettes
4. 200 Tests per hour
5. Probe with anti-collision function, liquid level dectection function.
1. Reaction Tray
37±0.1℃, real-time monitor
2. Reagent Tray
Refrigerated tray with independent switch.
3. Sample Needle
Liquid level sensor function. Anti-collision function. Reagent volume real-time detection.
4. Mixer Probe
Teflon coating to avoid cross contamination
5. Washing Probe
Independent 2-step washing system
6. LAN Port AccessWe emphasize advancement and introduce new products and solutions into the market each year for Low MOQ for China Olabo Manufacturer Bk-280 200 Tests Per Hour Auto Chemistry Analyzer, In buy to expand our international market, we mainly source our oversea customers Top top quality performance goods and services.
Low MOQ for China Auto Chemistry Analyzer, Our factory insists on the principle of “Quality First, Sustainable Development”, and takes “Honest Business, Mutual Benefits” as our developable goal. All members sincerely thanks for all old and new customers’ support. We will keep working hard and offering you the highest-quality solutions and service.Thanks.
Download: Bk-200mini(NEW BK-200)
