China New Product 200T/H Auto Chemistry Analyzer BK-200 For Lab clinical blood chemistry analyzer
We emphasize improvement and introduce new goods into the market each year for China New Product 200T/H Auto Chemistry Analyzer BK-200 For Lab clinical blood chemistry analyzer, In addition, we would properly tutorial the purchasers about the application techniques to adopt our items plus the way to select appropriate materials.
We emphasize improvement and introduce new goods into the market each year for China Chemistry Analyzer, Fully Auto Chemistry Analyzer, we’re now looking forward to even greater cooperation with overseas customers based on mutual benefits. We are going to work wholeheartedly to improve our products and services. We also promise to work jointly with business partners to elevate our cooperation to a higher level and share success together. Warmly welcome you to visit our factory sincerely.
Parameter
| Model | BK-200 | |
| Overall Performance | Throughput | 200 Tests/hour |
| Analysis Method | End-point, Fixed-time, Rate(Kinetic) | |
| Certification | CE, ISO9001, ISO14001, ISO13485 | |
| Sample & Reagent System | Sample Positions | 37 sample positions |
| Reagent Positions | 28 reagent positions | |
| Sample Volume | 2~70μl | |
| Reagent Volume | 20~350μl | |
| Probe | Teflon coating ,with anti-collision function, liquid leveldetection function | |
| Probe Washing | Automatic washing interior and exterior | |
| Reagent Cooling | Refrigerated tray with independent switch | |
| Reaction System | Temperature Control | 37±0.1℃, real-time monitoring |
| Cuvettes | 48 reusable cuvettes, optical length 6mm | |
| Mixer Probe | Independent stirring | |
| Washing | Automatic cuvettes washing | |
| STAT function | YES | |
| Optical System | Light Source | 6V/10W halogen lamp |
| Spectrophotometry | Post-spectral spectrophotometry | |
| Wavelength | 340,405,450,510,546,578,630,700nm | |
| Absorbance | 0~3.0Abs | |
| Calibration & QC | Calibration | Linear:K factor, 1-point, 2-point and multipoint linear Non-Linear:Spline,Polygon, Index, Ogarithm, Logit-4P, Logit-5P |
| Quality Control | Real-time QC, Westgard multi rule, Cumulative Sum Check,Twin Plot(2D) | |
| Data Management | Software | Windows 7/8/10 , 32or 64bit |
| LIS System | Bi-direction,support HL7 protocol | |
| Interface | LAN port access | |
| Printer | External, multiple reporting mode available | |
| Working Conditions | Power Supply | AC220V±10%,50/60Hz, 110V±10%,60Hz, 300W |
| Temperature | 10~30℃ | |
| Water Consumption | Deionized water:12L/H | |
| Humidity | 30-80% | |
| Size & Weight | External Size (W*D*H) | 625*425*460mm |
| Net Weight | 36kg | |
| Package Size (W*D*H) | 721*531*855mm | |
| Gross Weight | 50kg | |
Features
1. 37 Sample positions
2. 28 Reagent positions
3. 48 Reaction cuvettes
4. 200 Tests per hour
5. Probe with anti-collision function, liquid level dectection function.
1. Reaction Tray
37±0.1℃, real-time monitor
2. Reagent Tray
Refrigerated tray with independent switch.
3. Sample Needle
Liquid level sensor function. Anti-collision function. Reagent volume real-time detection.
4. Mixer Probe
Teflon coating to avoid cross contamination
5. Washing Probe
Independent 2-step washing system
6. LAN Port AccessWe emphasize improvement and introduce new goods into the market each year for Supply China Chemistry Analyzer Animal Blood Analyzer Lab Blood Testing Machine Vet Automatic Dry Chemistry Analyzer, In addition, we would properly tutorial the purchasers about the application techniques to adopt our items plus the way to select appropriate materials.
Supply China Chemistry Analyzer, Semi Auto Chemistry Analyzer, we’re now looking forward to even greater cooperation with overseas customers based on mutual benefits. We are going to work wholeheartedly to improve our products and services. We also promise to work jointly with business partners to elevate our cooperation to a higher level and share success together. Warmly welcome you to visit our factory sincerely.
