China Factory for China Peristaltic Pump
Our staff through skilled training. Skilled skilled knowledge, potent sense of company, to satisfy the provider requirements of consumers for China Factory for China Peristaltic Pump, We focus on building own brand and in combination with numerous experienced expression and first-class equipment . Our goods you worth have.
Our staff through skilled training. Skilled skilled knowledge, potent sense of company, to satisfy the provider requirements of consumers for China Pump, Peristaltic Pump, With top quality goods, great after-sales service and warranty policy, we win trust from many overseas partner, many good feedbacks witnessed our factory’s growth. With full confidence and strength, welcome customers to contact and visit us for future relationship.
Parameter
| Drive model | BT100M | BT300M | BT600M |
| Speed range | 0.1~100rpm(reversible) | 0.1~300rpm(reversible) | 0.1~600rpm(reversible) |
| speed resolution | 0.1rpm | ||
| Flow range | 0.0015~380ml/min | 0.007~1140ml/min | 0.007~2280ml/min |
| Filling Accuracy | ＜±0.5% | ||
| Flow calibration | Yes | ||
| Control Method | Rotary encoded knob | ||
| Display Mode | 4-LED display | ||
| Suckback speed | 10~100rpm | 10~300rpm | |
| Power supply | AC220V±10%(standard) or AC110V±10%(optional) | ||
| Power consumption | ＜22W | ＜35W | ＜50W |
| Environment Temperature | 0~40℃ | ||
| Relatively Humidity | ＜80%， No condensation | ||
| Drive size | 234*154*143mm | 254*184*150mm | |
| Drive weight | 5.15kg | 5.15kg | 5.8kg |
| Motor type | Stepper motor | ||
| IP grade | IP31 | ||
| Working mode | Transmission mode | ||
| External control | Start/stop, direction, speed (optional) RS485 serial communication Working environment relative humidity, no condensation |
||
| Rev. Stop status signal output | switching value signal output | ||
| Direction status signal output | switching value signal output | ||
| External control interface | DB-15 | ||
| External control | Control Rev. Stop,Direction,Speed.-Support RS485/MODBUS communication protocol , analog quantity control (0-5V 0-10V 4-20mA …)foot switch control. | ||
Advantage
* with three available modes: 0-5V, 0-10V and 4-20mA.
* Memory function is also available in the product in case of power off.
* Besides, switching knobs are designed clearly so that it is easy to operate for customers.
* FULL SPEED button available for filling in & emptying out.
* Cost-effective
Our staff through skilled training. Skilled skilled knowledge, potent sense of company, to satisfy the provider requirements of consumers for China Factory for China Peristaltic Pump, We focus on building own brand and in combination with numerous experienced expression and first-class equipment . Our goods you worth have.
China Factory for China Pump, Peristaltic Pump, With top quality goods, great after-sales service and warranty policy, we win trust from many overseas partner, many good feedbacks witnessed our factory’s growth. With full confidence and strength, welcome customers to contact and visit us for future relationship.
