-86 Laboratory Ultra Low Temperature Freezer BDF-86V168T
Key Parameters:
1. Temperature Range: -40~-86℃
2. Shelves: 2 pcs adjustable shelves
3. Microprocessor Control, 8 inch Touch Screen LCD
1. Temperature Range: -40~-86℃
2. Shelves: 2 pcs adjustable shelves
3. Microprocessor Control, 8 inch Touch Screen LCD
4. High and low temperature alarm, sensor fault alarm, power alarm, open and close abnormal alarm function
5. Lead time: In Stock
Specification
|
Model
|
BDF-86V168T
|
|
|
External Size(W*D*H) mm
|
844*807*1594mm
|
|
|
Internal Size(W*D*H) mm
|
465*455*820mm
|
|
|
Capacity
|
168L
|
|
|
Type
|
Vertical
|
|
|
Temp. Range
|
-40°C~-86°C
|
|
|
Temp. Accuracy
|
0.1°C
|
|
|
Control System
|
Microprocessor control, 8 inch touch LCD screen
|
|
|
Audible and Visual Alarm
|
High and low temperature alarm, sensor fault alarm, power alarm, open and close abnormal alarm function
|
|
|
Alarm Method
|
Sound beeps and lights flash, remote alarm
|
|
|
Refrigeration Type
|
Double machine cascade refrigeration system
|
|
|
Refrigerant
|
R290/150g R170/40g
|
|
|
Compressor
|
2 sets
|
|
|
Condenser& Evaporator
|
Made of copper
|
|
|
Construction |
Foam Layer Thickness
|
189mm
|
|
Internal Material
|
304 stainless steel
|
|
|
External Material
|
Cold rolled steel plate
|
|
|
Door
|
Lockable door
|
|
|
Caster
|
4 casters
|
|
|
Chamber with Inner Door
|
3
|
|
|
Shelf
|
2pcs
|
|
|
Temp. Test Port
|
1, Φ30mm
|
|
|
Consumption
|
830W
|
|
|
Power Supply
|
Standard: 220V 50Hz
Optional: 220V 60Hz, 110V, 60Hz |
|
|
Package Size (W*D*H) mm
|
1000x970x1790mm
|
|
|
Gross Weight
|
253kg
|
|
