OLABO Manufacturer High Pressure Sterilizer For PCR Lab
Parameter
| Model | BKQ-Z30I | BKQ-Z50I | BKQ-Z75I | BKQ-Z100I |
| Capacity | 30L | 50L | 75L | 100L |
| Chamber size(mm) | φ385*412 | φ385*515 | φ385*715 | φ385*915 |
| ChamberMaterial | SUS304 | |||
| MaxPressure | 0.3MPa | |||
| RatedWorkingPressure | 0.22MPa | |||
| MaxTemperature | 150℃ | |||
| WorkingTempRange | 105～134℃ | |||
| Temp.Display Accuracy | ±0.1℃ | |||
| TimingRange | 0-999min | |||
| DynamicPulseExhaustTime | 0~9times | |||
| WaterRequirement | Distilled water or demineralized water | |||
| Standard Accessories | Stainless steel basket*1pc | Stainless steel basket*2pcs | ||
| Consumption | 4KW | |||
| PowerSupply | AC110/220V±10%, 50/60Hz | |||
| External Size(W*D*H)mm | 645*610*710 | 645*610*850 | 645*610*1000 | 645*610*1200 |
| Packing Size(W*D*H)mm | 750*745*950 | 750*745*1100 | 750*745*1240 | 750*745*1450 |
| GrossWeight(kg) | 100 | 103 | 114 | 122 |
Safety Features
● Over pressure, safety valve can automatically open to release pressure.
● Over temperature, the system will stop heating automatically and start alarm.
● Anti dry-out function. If water level is too low, heating stops and error code displays on screen.
● Over current, over voltage or electric leakage protection apparatus-air switch.
Technical Features
● Complete protection system.
● Flip-open door structure with spring booster, easy to open.
● LED displays inner temperature, time and error codes.
● Automatic exhausting steam function.
● Reliable mechanical safety interlock feature.
● External material: Cold rolled steel with anti-bacteria powder coating.
● Fixed sterilization programs for dressings, unwrapped and wrapped equipment, rubber, and liquid.
● Door cover is wrapped completely, to prevent scald effectively.
● Radial self-expanding silicone rubber seals with high effect and long using life.
● Optional printer for recording sterilization data.
● Optional stainless stee bucket.
Download:
High Pressure Sterilizer
