OLABO Nucleic Acid Extraction System Machine Automatic DNA RNA Testing Extractor
OLABO Nucleic Acid Extraction System Machine Automatic DNA RNA Testing Extractor,
DNA RNA Testing Extractor,
Parameter
| Model | BK-HS32 |
| Multi-mode Operation | List mode, shortcut, view mode |
| Processing Volume | 20µL-1000µL |
| Sample Throughput | 1-32 |
| Magnetic Bead Recovery | >98% |
| Extracting the Difference Between Holes | CV≤3% |
| Heating Temperature | 8 independent heating modules, customize lysis and elution temperature (temperature range) according to your needs |
| Oscillating Mixing | Low,medium and high third gears are adjustable, and the fluctuation range can be adjusted with the reagent volume |
| Reagent Type | Magnetic bead open platform |
| Extraction Time | 15-60 min/round (depending on the reagent used) |
| Internal Program | Be able to store >500 groups of programs |
| Program Management | Powerful program editing capabilities to meet different reagent needs. U disk program import and export can be achieved |
| Safety Door Design | After the safety door is opened,the program operation will be automatically suspended, and the program can continue t run after the safety door is closed |
| Built-in Air Duct | Built-in air duct to avoid cross infection |
| Safety Protection | Support power-off protection and continuous operation after power is restored |
| Flashlight | Yes |
| Ultraviolet Irradiation | Yes |
| Package Size (W*D*H)mm | 538*538*750 |
| Gross Weight (KG) | 37 |
Advantage
1. Friendly user interface: Smart & Intelligent display.
With 10.1 inch LCD touch screen, Windows operating system.
2. Zero Aerosol ContaminationHigh efficiency HEPA filter and Auto safety door protection function, safety door protection function, HEPA filter and UV lamp
replacement HEPA filter and UV lamp replacement alarm functions.
3. UV Sterilization Lamp
*With manual or set automatic opening timeUV lamp,
sterilizing the operation area easily and effectively.
4. Integrated Shaking &Heating Module Mix deep wells while heating, saving extraction time.BNP32 / BNP48 System is a fully-automated clinical nucleic acid extraction system that brings you walk-away automation, designed to minimize user intervention and extraction-to-extraction variability. In addition to providing quality purified eluates, the BNP32 / BNP48 System offers onboard primary-sample handling and mixed-batch sampling for up to 32 or 48 samples per run.
The nucleic acid extractor is a high-tech product that uses the universal magnetic bead method to extract nucleic acids, and has an automated process.
It has the advantages of high accuracy, fast extraction speed, stable results, and easy operation. Using a dedicated 96-well deep-well plate, 1-32 samples can be operated at the same time.
Use the magnetic rod on the magnetic rod rack of the experimental cabin to move the magnetic beads with nucleic acid to different.
In the reagent well, a stirring sleeve sheathed on the outer layer of the magnetic rod is used to repeatedly and quickly stir the liquid to make the liquid and the magnetic beads uniformly mixed. After cell lysis, nucleic acid adsorption, washing and elution, high-purity nucleic acid is finally obtained.
